Written by Dr. Vincent Gray
Chapter 13 of the IPCC 5th WGI Report claims that sea level will rise by an amount between 0.26 to 0.97 metres by 2100 according to which of their new scenarios actually happens.
Relative Sea Level, the distance between the level of the sea and the level of neighbouring land, is what matters to most of us. The Level of the open ocean is only of minor importance. This Report tries to mix the two up in a single chart.
Relative Sea Level is measured by tide gauges which measure the distance between the level of the sea registered on specialist equipment and a supposedly constant benchmark location on the neighbouring land. This is carried out in over 1,000 coastal locations all over the world. The records are averages, over a day, week, month or years.
Both the level of the sea and of the neighbouring land constantly vary from place to place.and from time to time. The sea changes level constantly, diurnally and seasonally. It is influenced by winds, storms and hurricanes and also by earthquakes. The level of the sea may be influenced by breakwaters and harbour works. The equipment may be damaged or its location altered by storms. Severe storms may prevent correct measurement and give a false reading which interferes with claims for “change.”
Land surfaces may change. The land may subside by weight of buildings, and removal of minerals and groundwater. The Report illustrates the problem of measurement near land covered in ice. Geological change (Isostasy) may result from plate movements and earthquakes. Many of these effects cause an upwards bias to the readings.
Long term trends may as much show these changes as any other influence. As a result they are not a reliable guide to the future, which should be based on a recent period of reliable measurements.
The recent installation of GPS levelling equipment on many sites has greatly improved the reliability of the land-based benchmark. It has resulted in a nearly constant sea level change for many records. It is therefore wrong to place reliance on older readings in order to assess future behaviour. It should be based on the most recent measurements which are the least likely to be affected by previous bias.
The records are publicly available at the Permanent Service for Mean Sea Level (PSMSL) website at athttp://www.psmsl.org/data/obtaining/map.html which features a very convenient map of the world from which all the records can be obtained.
Many records are defective in one way or another. Many have gaps or sudden changes. Few have a long-term continuous record. Frequently there is little sign of change during the recent decade – evidence. that currently there is little or no change in sea level. The following figure from Chapter 13, FAQ 13.1 Figure 1. illustrates this error.
It shows six tide gauge records compared with the supposed global average.
The actual current records, which are shown (rather small), disagree with this supposed trend:
San Francisco is unchanged since 1990.
Charlottetown is unchanged from 1995 to 2010.
Antofagasta is unchanged from 1980 to 2012
Pago Pago is unchanged since 2000.
Stockholm is actually falling.
Manila is a rogue record.
